SIZE |
PR |
Loading Index |
Speed Rating |
Tread Depth |
Inflatable Section Width(mm) |
Standard Rim |
Overall Diameter(mm) |
MAX Load |
MAX Pressure |
Sidewall Description |
||
KG |
1bs |
Kpa |
PSI |
|||||||||
| P205/75R15 | – | 97 | T | 8.2 | 203 | 5 1/2J | 689 | 725 | 1598 | 300 | 44 | OWL |
| P215/75R15 | – | 100 | T | 8.2 | 216 | 6J | 703 | 800 | 1764 | 300 | 44 | OWL |
| P225/75R15 | – | 102 | T | 8.2 | 223 | 6J | 719 | 850 | 1874 | 300 | 44 | OWL |
| P235/75R15XL | – | 109 | S | 8.7 | 235 | 6 1/2J | 733 | 1030 | 2271 | 340 | 50 | OWL |
| P265/70R15 | – | 112 | T | 9.2 | 272 | 8J | 753 | 1120 | 2469 | 300 | 44 | OWL |
| P215/70R16 | – | 100 | T | 8.2 | 221 | 6 1/2J | 708 | 800 | 1764 | 300 | 44 | BSW |
| P215/70R16 | – | 99 | T | 8.2 | 221 | 6 1/2J | 708 | 775 | 1709 | 300 | 44 | BSW |
| P225/70R16 | – | 101 | T | 8.2 | 228 | 6 1/2J | 722 | 825 | 1819 | 300 | 44 | OWL |
| P225/70R16 | – | 103 | T | 8.2 | 228 | 6 1/2J | 722 | 875 | 1929 | 300 | 44 | OWL |
| P235/70R16 | – | 106 | T | 8.8 | 240 | 7J | 736 | 950 | 2094 | 300 | 44 | OWL |
| P235/70R16 | – | 104 | T | 8.8 | 240 | 7J | 736 | 900 | 1984 | 300 | 44 | OWL |
| P245/70R16 | – | 107 | T | 8.8 | 248 | 7J | 750 | 975 | 2149 | 300 | 44 | OWL |
| P245/70R16XL | – | 111 | S | 8.8 | 248 | 7J | 750 | 1090 | 2403 | 340 | 50 | OWL |
| P245/70R16 | – | 106 | T | 8.8 | 248 | 7J | 750 | 950 | 2094 | 300 | 44 | OWL |
| P255/70R16 | – | 109 | T | 9.2 | 260 | 7 1/2J | 764 | 1030 | 2271 | 300 | 44 | OWL |
| P255/70R16 | – | 111 | T | 9.2 | 260 | 7 1/2J | 764 | 1090 | 2403 | 300 | 44 | OWL |
| P265/70R16 | – | 112 | T | 9.2 | 272 | 8J | 778 | 1120 | 2469 | 300 | 44 | OWL |
| P265/70R16 | – | 111 | T | 9.2 | 272 | 8J | 778 | 1090 | 2403 | 300 | 44 | OWL |
| P275/70R16 | – | 114 | T | 9.2 | 279 | 8J | 792 | 1180 | 2601 | 300 | 44 | OWL |
| P235/65R17 | – | 104 | T | 8.8 | 240 | 7J | 738 | 900 | 1984 | 300 | 44 | BSW |
| P245/65R17 | – | 107 | T | 8.8 | 248 | 7J | 750 | 975 | 2149 | 300 | 44 | BSW |
| P255/65R17 | – | 110 | T | 8.7 | 260 | 7 1/2J | 764 | 1060 | 2337 | 300 | 44 | OWL |
| P265/65R17 | – | 110 | T | 8.7 | 272 | 8J | 776 | 1060 | 2337 | 300 | 44 | OWL |
| P265/65R17 | – | 112 | T | 8.7 | 272 | 8J | 776 | 1120 | 2469 | 300 | 44 | OWL |
| P265/70R17 | – | 113 | T | 9.2 | 272 | 8J | 804 | 1150 | 2535 | 300 | 44 | OWL |
| P265/70R17 | – | 115 | T | 9 | 272 | 8J | 804 | 1215 | 2679 | 300 | 44 | OWL |
| P275/65R17 | – | 115 | T | 9.2 | 279 | 8J | 790 | 1215 | 2679 | 300 | 44 | OWL |
| P275/55R20XL | – | 117 | T | 8.7 | 284 | 8 1/2J | 810 | 1285 | 2833 | 340 | 50 | BSW |
| P275/60R20XL | – | 119 | T | 8.7 | 279 | 8J | 838 | 1360 | 2998 | 340 | 50 | BSW |
| 185/75R16C | 8PR | 104/102 | S | 8.1 | 184 | 5J | 684 | 900/850 | 1985/1875 | 450 | 65 | BSW |
| 205R16C | 8PR | 110/108 | S | 8.2 | 208 | 6J | 736 | 1060/1000 | 2335/2205 | 450 | 65 | BSW |
| 215R15C | 8PR | 112/110 | S | 8.7 | 218 | 6J | 725 | 1120/1060 | 2470/2337 | 450 | 65 | BSW |
| 215/70R15C | 8PR | 109/107 | R | 8.2 | 221 | 6 1/2J | 683 | 1030/975 | 2270/2150 | 450 | 65 | BSW |
| 245/75R15C | 6PR | 109/107 | S | 11.2 | 248 | 7J | 749 | 1030/975 | 2270/2150 | 375 | 55 | BSW |
| 255/70R15C | 6PR | 112/110 | S | 8.2 | 260 | 7 1/2J | 739 | 1120/1060 | 2470/2335 | 375 | 55 | BSW |
| LT235/75R15 | 6PR | 104/101 | S | 11.2 | 235 | 6 1/2J | 733 | 900/825 | 1985/1820 | 350 | 50 | OWL |
| 31×10.50R15LT | 6PR | 109 | S | 11.7 | 268 | 8 1/2J | 775 | 1030 | 2270 | 350 | 51 | OWL |
| LT215/85R16 | 10PR | 115/112 | S | 10.9 | 216 | 6J | 772 | 1215/1120 | 2680/2470 | 550 | 80 | OWL |
| LT225/75R16 | 10PR | 115/112 | S | 10.9 | 223 | 6J | 744 | 1215/1120 | 2680/2470 | 550 | 80 | OWL |
| LT225/75R16 | 12PR | 119/116 | Q | 11.2 | 223 | 6J | 744 | 1360/1250 | 3000/2755 | 650 | 95 | OWL |
| LT235/85R16 | 10PR | 120/116 | S | 11.7 | 235 | 6 1/2J | 806 | 1380/1260 | 3042/2778 | 550 | 80 | BSW |
| LT245/75R16 | 10PR | 120/116 | S | 11.3 | 248 | 7J | 774 | 1380/1260 | 3042/2778 | 550 | 80 | OWL |
| LT265/75R16 | 10PR | 123/120 | S | 11.7 | 267 | 7 1/2J | 804 | 1550/1400 | 3415/3085 | 550 | 80 | OWL |
| LT285/75R16 | 8PR | 122/119 | S | 11.6 | 286 | 8J | 834 | 1500/1360 | 3305/3000 | 450 | 65 | OWL |
| LT245/75R17 | 10PR | 121/118 | S | 11.2 | 248 | 7J | 800 | 1450/1320 | 3195/2910 | 550 | 80 | OWL |
| LT265/70R17 | 10PR | 121/118 | S | 11.7 | 272 | 8J | 804 | 1450/1320 | 3195/2910 | 550 | 80 | OWL |
| LT275/65R18 | 10PR | 123/120 | S | 11.2 | 278 | 8J | 815 | 1550/1400 | 3415/3085 | 550 | 80 | BSW |
| LT275/70R18 | 10PR | 125/122 | S | 11.2 | 279 | 8J | 843 | 1650/1500 | 3640/3305 | 550 | 80 | BSW |
