Longitudinal zigzag pattern design, good driving and braking performance;
Combination of zigzag grooves and transverse grooves, strong traction, anti-skid; open shoulder design, improve tire heat dissipation performance.
Long-distance fixed-load guide tugs on high-speed or first-class highways.
Size |
PR |
Load Index |
Speed |
Diameter(mm) |
S.W/mm |
T.D/mm |
Rim |
Single Load/Pressure |
Dual Load/Pressure |
| 6.50R16LT | 12PR | 110/105 | L | 747 | 181 | 11 | 5.50F | 1060/670 | 925/670 |
| 7.00R16LT | 14PR | 118/114 | L | 770 | 197 | 12 | 5.50F | 1320/770 | 1180/770 |
| 7.50R16LT | 14PR | 122/118 | L | 803 | 211 | 13 | 6.00G | 1500/770 | 1320/770 |
| 8.25R16LT | 16PR | 128/124 | J | 857 | 232 | 14 | 6.50H | 1800/770 | 1600/770 |
| 8.25R20 | 16PR | 139/137 | J | 974 | 233 | 14 | 6.5 | 2430/930 | 2300/930 |
| 9.00R20 | 16PR | 144/142 | K | 1021 | 259 | 15.5 | 7.0 | 2800/900 | 2650/900 |
| 10.00R20 | 18PR | 149/146 | J | 1056 | 278 | 16.5 | 7.5 | 3250/930 | 3000/930 |
| 11.00R20 | 18PR | 152/149 | J | 1091 | 293 | 17 | 8.0 | 3550/930 | 3250/930 |
| 12.00R20 | 18PR | 154/151 | K | 1125 | 305 | 17 | 8.5 | 3750/830 | 3450/830 |
| 11R22.5 | 18PR | 149/146 | L | 1054 | 279 | 14.5 | 8.25 | 3250/930 | 3000/930 |
| 12R22.5 | 18PR | 152/149 | J | 1082 | 298 | 14.5 | 9.00 | 3550/930 | 3250/930 |
| 315/80R22.5 | 20PR | 157/154 | K | 1076 | 312 | 15 | 9.00 | 4125/900 | 3750/900 |
