Advantages:
1.The unique three broken fold line pattern with excellent traction performance and anti-eccentric wear
broken characteristic.
2.Four rigid belt Iayers, with excellent burst resistance and puncture resistance ability.
3.Optimized tire contact pressure distribution, prolong the tyre usage life
Applications:
Designed for heavy duty, middle and long distance transportation, high-speed vehicles on good road,
suitable for all wheels of trucks.
| SUPERWIN | SIZE | Ply Rating | Standard Rim |
Load Index | Air Pressure kpa / psi |
Daul Load kg/lbs |
Single Load kg/lbs |
Pattern Depth (mm) |
Tread Width (mm) |
| SU188 | 7.50R16 | 16 | 6.00G | 122/118 | 770/110 | 1320/2912 | 1500/3310 | 12 | 190 |
| 8.25R16 | 18 | 6.50H | 128/124 | 770/110 | 1600/3530 | 1800/3970 | 13 | 210 | |
| 9.00R20 | 16 | 7 | 144/142 | 900/130 | 2650/5840 | 2800/6170 | 16 | 220 | |
| 12.00R20 | 20 | 8.5 | 156/153 | 900/130 | 3650/8050 | 4000/8820 | 16.5 | 235 | |
| 11.00R20 | 18 | 8 | 152/149 | 930 135 | 3250 7170 | 3550 7830 | 16.5 | 225 |
