•The diamond-cut design of the tire shoulder enhances the bite with the snow and mud on the ground to avoid slipping.
•The meandering horizontal grooves, ice skates and daggers are staggered and matched, which can effectively cut the ice layer, improve the grip on ice and snow, and enhance the control performance.
•Through accurate calculation, the steel nails are evenly and randomly arranged horizontally and vertically, which not only ensures stable grip, but also reduces noise and vibration.
•The design of multi-layer rubber with different hardness and double flange nails ensures that the tread is soft enough and can lock the nails at the same time, improving the ice performance of the tire.
Sizes |
PR |
Loading Index |
Speed Rating |
Tread Depth |
Inflatable Section Width(mm) |
Standard Rim |
Overall Diameter(mm) |
UTQG |
MAX Load |
MAX Pressure |
Sidewall Description |
||
KG |
1bs |
Kpa |
PSI |
||||||||||
| 195/55R16 | – | 87 | T | 9 | 201 | 6 | 620 | – | 545 | 1202 | 300 | 44 | BSW |
| 215/65R17XL | – | 103 | T | 9.5 | 221 | 6.5 | 712 | – | 875 | 1929.012346 | 340 | 50 | BSW |
| 235/55R17XL | – | 103 | T | 9.5 | 245 | 7.5 | 690 | – | 875 | 1929.012346 | 340 | 50 | BSW |
| 215/55R18XL | – | 99 | T | 9.5 | 226 | 7 | 693 | – | 775 | 1708.553792 | 340 | 50 | BSW |
| 225/55R19XL | – | 103 | T | 9.5 | 233 | 7 | 731 | – | 875 | 1929.012346 | 340 | 50 | BSW |
| 205/70R15 | – | 96 | T | 9 | 209 | 6 | 669 | – | 710 | 1565.255732 | 300 | 44 | BSW |
| 175/70R13 | – | 82 | T | 9 | 177 | 5 | 576 | – | 475 | 1047.178131 | 300 | 44 | BSW |
| 175/65R14XL | – | 86 | T | 9 | 177 | 5 | 584 | – | 530 | 1168.430335 | 340 | 50 | BSW |
| 185/60R14 | – | 82 | T | 9 | 189 | 5.5 | 578 | – | 475 | 1047.178131 | 300 | 44 | BSW |
| 185/65R14XL | – | 90 | T | 9 | 189 | 5.5 | 596 | – | 600 | 1322.751323 | 340 | 50 | BSW |
| 195/55R15 | – | 85 | H | 9 | 201 | 6 | 595 | – | 515 | 1135.361552 | 300 | 44 | BSW |
| 185/60R15XL | – | 88 | T | 9 | 189 | 5.5 | 603 | – | 560 | 1234.567901 | 340 | 50 | BSW |
| 195/60R15XL | – | 92 | T | 9 | 201 | 6 | 615 | – | 630 | 1388.888889 | 340 | 50 | BSW |
| 185/65R15XL | – | 92 | T | 9 | 189 | 5.5 | 621 | – | 630 | 1388.888889 | 340 | 50 | BSW |
| 195/65R15XL | – | 95 | T | 9 | 201 | 6 | 635 | – | 690 | 1521.164021 | 340 | 50 | BSW |
| 205/55R16XL | – | 94 | T | 9 | 214 | 6.5 | 632 | – | 670 | 1477.07231 | 340 | 50 | BSW |
| 205/60R16XL | – | 96 | T | 9 | 209 | 6 | 652 | – | 710 | 1565.255732 | 340 | 50 | BSW |
| 215/60R16XL | – | 99 | T | 9 | 221 | 6.5 | 664 | – | 775 | 1708.553792 | 340 | 50 | BSW |
| 205/65R16 | – | 95 | T | 9 | 209 | 6 | 672 | – | 690 | 1521.164021 | 300 | 44 | BSW |
| 215/65R16XL | – | 102 | T | 9 | 221 | 6.5 | 686 | – | 850 | 1873.897707 | 340 | 50 | BSW |
| 215/70R16 | – | 100 | T | 9 | 221 | 6.5 | 708 | – | 800 | 1763.66843 | 300 | 44 | BSW |
| 235/70R16 | – | 106 | T | 9 | 240 | 7 | 736 | – | 950 | 2094.356261 | 300 | 44 | BSW |
| 245/70R16XL | – | 111 | T | 9 | 248 | 7 | 750 | – | 1090 | 2402.998236 | 340 | 50 | BSW |
| 185/75R16C | 8PR | 104/102 | R | 11 | 184 | 5 | 684 | – | 900/850 | 1985/1875 | 475 | 69 | BSW |
| 195/75R16C | 8PR | 107/105 | R | 11 | 196 | 5.5 | 698 | – | 975/925 | 2150/2040 | 475 | 69 | BSW |
| 225/65R16C | 8PR | 112/110 | R | 11 | 228 | 6.5 | 698 | – | 1120/1060 | 2470/2335 | 475 | 69 | BSW |
| 235/65R16C | 12PR | 121/119 | R | 11 | 240 | 7 | 712 | – | 1450/1360 | 3195/3000 | 575 | 83 | BSW |
| LT225/75R16 | 10PR | 115/112 | S | 11 | 223 | 6 | 744 | – | 1215/1120 | 2680/2470 | 550 | 80 | BSW |
| 225/45R17XL | – | 94 | H | 9.5 | 225 | 7.5 | 634 | – | 670 | 1477.07231 | 340 | 50 | BSW |
| 205/50R17XL | – | 93 | T | 9.5 | 214 | 6.5 | 638 | – | 650 | 1432.9806 | 340 | 50 | BSW |
| 215/50R17XL | – | 95 | T | 9.5 | 226 | 7 | 648 | – | 690 | 1521.164021 | 340 | 50 | BSW |
| 225/50R17XL | – | 98 | H | 9.5 | 233 | 7 | 658 | – | 750 | 1653.439153 | 340 | 50 | BSW |
| 215/55R17XL | – | 98 | T | 9.5 | 226 | 7 | 668 | – | 750 | 1653.439153 | 340 | 50 | BSW |
| 225/55R17XL | – | 101 | H | 9.5 | 233 | 7 | 680 | – | 825 | 1818.783069 | 340 | 50 | BSW |
| 215/60R17XL | – | 100 | T | 9.5 | 221 | 6.5 | 690 | – | 800 | 1763.66843 | 340 | 50 | BSW |
| 225/60R17XL | – | 103 | T | 9.5 | 228 | 6.5 | 702 | – | 875 | 1929.012346 | 340 | 50 | BSW |
| 225/65R17XL | – | 106 | T | 9.5 | 228 | 6.5 | 724 | – | 950 | 2094.356261 | 340 | 50 | BSW |
| 235/65R17XL | – | 108 | T | 9.5 | 240 | 7 | 738 | – | 1000 | 2204.585538 | 340 | 50 | BSW |
| 265/65R17XL | – | 116 | T | 9.5 | 272 | 8 | 776 | – | 1250 | 2755.731922 | 340 | 50 | BSW |
| LT265/70R17 | 10PR | 121/118 | S | 11 | 272 | 8 | 804 | – | 1450/1320 | 3195/2910 | 550 | 80 | BSW |
| 235/45R18XL | – | 98 | T | 9.5 | 236 | 8 | 669 | – | 750 | 1653.439153 | 340 | 50 | BSW |
| 245/45R18XL | – | 100 | T | 9.5 | 243 | 8 | 677 | – | 800 | 1763.66843 | 340 | 50 | BSW |
| 225/55R18XL | – | 102 | T | 9.5 | 233 | 7 | 705 | – | 850 | 1873.897707 | 340 | 50 | BSW |
| 235/55R18XL | – | 104 | T | 9.5 | 245 | 7.5 | 715 | – | 900 | 1984.126984 | 340 | 50 | BSW |
| 225/60R18XL | – | 104 | T | 9.5 | 228 | 6.5 | 727 | – | 900 | 1984.126984 | 340 | 50 | BSW |
| 235/60R18XL | – | 107 | T | 9.5 | 240 | 7 | 739 | – | 975 | 2149.470899 | 340 | 50 | BSW |
| 285/60R18 | – | 116 | T | 9.5 | 292 | 8.5 | 799 | – | 1250 | 2755.731922 | 300 | 44 | BSW |
| 265/60R18XL | – | 114 | T | 9.5 | 272 | 8 | 775 | – | 1180 | 2601.410935 | 340 | 50 | BSW |
| 235/55R19XL | – | 105 | T | 9.5 | 245 | 7.5 | 741 | – | 925 | 2039.241623 | 340 | 50 | BSW |
| 235/55R20 | – | 102 | T | 9.5 | 245 | 7.5 | 766 | – | 850 | 1873.897707 | 300 | 44 | BSW |
| 245/50R20XL | – | 105 | T | 9.5 | 253 | 7.5 | 754 | – | 925 | 2039.241623 | 340 | 50 | BSW |
| 245/45R20XL | – | 103 | T | 9.5 | 243 | 8 | 728 | – | 875 | 1929.012346 | 340 | 50 | BSW |
